| CUTTING | | Max Log Capacity | 21″ Diameter | | Distance Between Guide | 19″ | | Max Thickness of Cut | 9″ | | Standard Track Length | 12′ / 2 – 6′ Sections | | Log Dogs | 2 Cam Style Dogs & Square Posts | | Max Log Length (with standard track) | 9′ | | Blade | 132 X 1.25 X .035″ | | Blade Lubrication | 2.5 Gallon | | Track Sweeps | No | | POWER | | Engine / Motor | 6.5hp Gas – Manual Start | | Clutch Engagement | Centrifugal | | CONSTRUCTION | | Frame | Modified 4 post | | Bandwheels | 16″ | | Guide System | Dual Shoe Guides, Fixed | | Lift System | Manual Cable | | Measuring | Dual Scale 1″and 4,5,6,8 Quarter | | Main Bearings | 1.5″ | | WARRANTY | | 3-Year Limited Warranty | Residential Use | | 6-Year Warranty | Main Shafts and Bearings |
|
